● Tested under real transport conditions● 51,000+ data points● Dual temperature monitoring
UltraST Cold Chain PCM

Safer Temperature Control
for Vaccines & Biopharma
Shipments

Designed for cargo that cannot afford temperature excursions or contamination.

5°C is the validated lead configuration · Customizable temperature points available

[email protected]
+11.4h
Compliance Buffer
39.6h vs 28.2h
2.6×
Faster Turnover
4 vs 1.5 cycles/day
0
Leakage Risk
All-solid-state

www.passive-edge.cn

Risk Identification

What happens when your cold-chain goes wrong?

Click each scenario to see the risk consequence and how UltraST reduces it

⏱

If your shipment is delayed by 8–10 hours, will it still stay compliant?

Click to see risk details →

🌡

After frequent lid openings, how fast can the temperature recover?

Click to see risk details →

🔄

Is your current PCM slowing down your entire operation?

Click to see risk details →

💧

What happens if leakage contaminates the shipment?

Click to see risk details →

The Numbers That Matter

Why switch to UltraST — right now?

Based on real comparative testing under identical conditions

+11.4h
Extra Compliance Window
39.6h vs 28.2h — real buffer against delays
2.6×
Daily Turnover Improvement
~4 cycles/day vs ~1.5 cycles/day
10.2
Min Thermal Recovery
vs Ice Pack 26.4 min — 2.6× faster
0
Leakage Contamination Risk
All-solid-state — no liquid contamination pathway

What You Actually Gain

Same operation. More output. Less risk.

📦
Fewer PCM packs required
4 cycles/day vs 1.5 — far fewer sets needed
⚡
Faster daily turnover
57 min recharge vs 129.5 min — 2.6× more batches/day
🏭
Lower cold storage dependency
Faster recharge = fewer sets waiting in cold storage
🛡
Reduced excursion risk
+11.4h window + 10.2 min recovery after each opening

Evidence Base

Key claims backed by comparative testing

12°C
Ambient Temp
45L
Insulated Box
3.21 kg
Equal PCM Weight
2-Stage
Two-Stage Test
T1/T2/T3
3-Point Monitor
51,000+
Data Records

All data below is derived from real comparative testing — not theoretical models or marketing estimates. Test conditions simulate real transport scenarios with dual-stage monitoring and 51,000+ recorded data points.

Core Decision Data

If your shipment is delayed, what happens next?

An extra 11.4 hours is not just time — it is protection against real-world uncertainty

Compliance Window Comparison

Ice Pack28.2h
Compliant
Risk Zone
UltraST39.6h
Fully Compliant
+11.4h
Extra Safety Window
This is the difference between failure and safe delivery.
Traditional Ice PackHigh Excursion Risk
28.2h→ reaches risk zone
8.0°C→ T3 at 45.6h

After 8h delay, cargo exceeds compliant temperature range

UltraST PCMStill Within Compliant Range
39.6h→ still compliant
6.5°C→ T3 at 45.6h

After 8h delay, cargo remains within 2–8°C compliant range

T3 Product Temperature — Comparative Test Results

UltraSTIce Pack8°C limit
012345678910111213141516171819202122232425262728293031323334353637383940414243444546Hours2°C5°C8°C12°C8°C
▲ Ice pack exceeds limit at 28.2h✓ UltraST compliant at 39.6h△ At 45.6h: Ice 8.0°C vs UltraST 6.5°C

Operational Efficiency

Faster recovery means more shipments per day

Faster recovery reduces waiting time, lowers PCM inventory requirements, and improves operational throughput

Recharge Time

UltraST57 min
Ice Pack129.5 min

UltraST 2.3× faster

Daily Cycles

UltraST~4 cycles
Ice Pack~1.5 cycles

2.6× turnover improvement

PCM Sets Needed

UltraSTFewer
Ice PackMore

Lower inventory requirement

ROI Calculator

How much can you save by switching to UltraST?

Enter your operational parameters for an instant annual savings estimate

10

batches/day

20

sets

$15

USD/set/day

Calculation Result (based on 8-hour working day)

4
Ice Pack Sets Needed
2
UltraST Sets Needed
-2
Sets Saved
$10,950
Est. Annual Savings

Formula: Ice sets = ⌈batches ÷ (480÷129.5)⌉; UltraST sets = ⌈batches ÷ (480÷57)⌉; Annual savings = sets saved × daily cost × 365. Assumptions: 8h working day, equal PCM weight, holding cost includes procurement/storage/cleaning.

High-Frequency Handling Risk

Every lid opening is a temperature risk

In high-frequency handling scenarios, this difference compounds over time. Recovery speed after each opening directly determines cumulative excursion risk.

Recovery After Lid Opening

UltraST
10.2 min
vs
Ice Pack
26.4 min

T3 Temp After Opening

UltraST
4.1°C
vs
Ice Pack
5.3°C
Pharma SortingHigh-Freq HandoffSame-City Cold ChainFrequent Lid Opening
UltraST PCM Module
✓ Top 100 Global Open Innovation✓ WIPO Green Database Auth.✓ RAL Certified Organization✓ Patented Product
ULTRAST PCM
High Thermal Conductivity PCM Module
10 W/m·K
Conductivity
vs 0.21
10,000+
Cycle Life
cycles
-0.18 kg
Lighter
per set
-0.5 L
Smaller
per set

Contamination Risk

Temperature is not the only risk — contamination is worse

A single leakage event can compromise the entire shipment

Traditional Liquid Ice Pack
✕Liquid phase-change material — leakage pathway exists
✕Transport vibration or puncture can cause leakage
✕Leakage contaminates every item in the shipment
✕Vaccines and biopharma specimens face write-off risk
UltraST — All-Solid-State Structure
✓All-solid-state composite — no liquid phase
✓Even if packaging is damaged, no liquid contaminants
✓Eliminates the leakage contamination risk pathway entirely
✓Specifically suited for vaccines, biologics, high-value specimens
💉
Vaccine Transport
🧬
Biopharma Specimens
🔬
High-Value Specimens
🛡
Contamination-Sensitive

Decision Tool

Quick Suitability Check

Answer 6 questions to get an instant suitability assessment

Daily shipment batches

Single shipment duration

Frequency of lid openings

Cargo value level

Contamination sensitivity

Current ice pack sets in use

UltraST PCM Module — Full Product View

Designed For

Designed for different sensitive cold-chain use cases

Vaccine Transport

Vaccines & Biologics

▲Core risk: Temperature excursion renders product non-recoverable
—Ice pack gap: Narrow compliance window — any delay is a failure
✓UltraST value: 39.6h hold + zero leakage — maximum safety margin for vaccine shipments
Biopharma Specimens

Biopharma Trial Specimens

▲Core risk: Contamination or excursion invalidates trial data
—Ice pack gap: Leakage risk directly contaminates specimens
✓UltraST value: All-solid-state, zero leakage — protects specimen integrity
Pharma Distribution

Pharmaceutical Cold Chain

▲Core risk: Frequent lid openings cause cumulative excursion
—Ice pack gap: 26.4 min recovery — unsuitable for high-frequency operations
✓UltraST value: 10.2 min recovery, 4 cycles/day — built for high-frequency pharma distribution
High-Value Specimens

High-Value Temperature-Sensitive Cargo

▲Core risk: Any failure results in irreversible loss
—Ice pack gap: Insufficient safety margin for high-stakes cargo
✓UltraST value: Higher safety margin, stronger delivery certainty

Temperature Platform

5°C is our validated starting point — not the limit

UltraST is not a single-temperature product, but a customizable thermal solution for different transport requirements. This page showcases the 5°C validated configuration — but our capability extends beyond this.

2–8°C
Pharma Cold Chain Standard
Validated
-20°C
Frozen Transport
Customizable
Custom
Special Temperature Range
Engineering Consult

Tested. Measured. Verified.

Real testing. Real product. Real capability.

📦
Real Insulated Box
45L · 12°C ambient
🌡
3-Point Monitoring
T1 / T2 / T3 sensors
📊
51,000+ Data Points
Suitable for trend analysis
⚖️
Equal-Weight Comparison
3.21 kg PCM net weight
High-Stakes Vaccine Shipments
● Vaccine Transport

High-Stakes Vaccine Shipments

Every batch is irreplaceable. UltraST's 39.6h compliance window absorbs real-world delays at every airport handoff.

Biopharma Specimen Integrity
● Biopharma Storage

Biopharma Specimen Integrity

Zero liquid phase means zero contamination risk. Solid-state design protects biologics from leakage-induced loss.

Clinical Trial Sample Transport
● Clinical Trials

Clinical Trial Sample Transport

Trial data integrity starts with temperature integrity. 10.2-min recovery after every lid opening keeps specimens compliant.

Oncology & High-Value Biologics
● Oncology & Biologics

Oncology & High-Value Biologics

When failure is not an option. Precision 5°C control with maximum safety margin for irreplaceable cargo.

Real-World Scenario

Imagine This Scenario

⏳
Shipment Delayed

Customs hold adds 6 hours. Cargo sits in transit.

Ice Pack: <2h safety margin remaining
UltraST: >5h safety margin remaining
📦
Multiple Handling

Box opened 3 times during sorting. Warm air enters each time.

Ice Pack: 26.4 min recovery each time — cumulative excursion
UltraST: 10.2 min recovery — minimal risk accumulation
🌡️
Final Delivery

48 hours later. Cargo arrives. Box opened for inspection.

Ice Pack: Cargo likely out of compliance — batch at risk
UltraST: Cargo still within safe temperature range

Your cargo still remains within safe temperature range.

That is why operators choose UltraST.

Fit Assessment

Is UltraST Right for You?

✓
Best Fit
High-value cargo (vaccines, biologics, specimens)
Long-distance or international transport
Frequent handling or high-frequency sorting
Cannot afford batch write-off or compliance failure
Contamination-sensitive cargo
–
Not the Right Fit
Low-cost bulk goods with no temperature sensitivity
Short-haul transport under 10 hours
Operations where cost is the only decision factor

If your cargo cannot afford any failure, you are the right customer.

Next Step

Choose safer thermal protection for your next shipment

Best for customers who cannot afford failure in cold-chain transport

[email protected]
🧪

Get Sample

See real performance in your own operation

Receive UltraST samples and validate performance in your actual transport conditions

📊

Download Test Summary

Understand the data behind the results

PDF with full comparative data, test methodology, and key conclusions

💬

Contact Us

Get a customized solution

Speak directly with our engineering team to assess fit and design a custom solution

Leave your details — we'll respond within 24 hours

Or email us directly:[email protected]
